MEAN WELL HDR-100-24 Industrial power supply for DIN rail, 100W, 24V

The HDR-100 series power supplies are affordable ultra-thin power supplies. The HDR-100-24 model provides a direct current output voltage of 24V with adjustable range from 24V to 25.5V. It is mounted on DIN rails TS-35/7.5 and TS-35/15, occupying 70mm in width (equivalent to 4SU). The power supply is ready for a wide input voltage range from 85 V AC to 264 V AC and meets the European standard EN 61000-3-2.

The outer casing of the power supply is made of plastic, effectively protecting against electric shock. With efficiency up to 90%, the power supply can operate in a temperature range of -30 to 70 °C. Thanks to the constant current supply and overload protection, it has wide application possibilities in both domestic and industrial installations.

Key Features

• Output voltage of 24 V DC with regulation from 24 to 25.5 V DC
• Mounting on DIN rails TS-35/7.5 and TS-35/15
• Wide input range 85 to 264 V AC
• Efficiency up to 90%
• Plastic housing with protection against electric shock
• Constant current mode
• Overload protection
