MEAN WELL HDR-15-24 Industrial power supply for DIN rail, 15W, 24V

HDR-15 series power supplies are affordable ultra-thin power supplies. This model provides a direct current output voltage of 24 V with adjustable range from 21.6 V to 29 V. It is mounted on a DIN rail, taking up 17.5 mm in width. The power supply is ready for a wide input voltage range from 85 V AC to 264 V AC and meets the European standard EN 61000-3-2.

The external casing of the power supply is made of plastic, which effectively protects against electric shock. With efficiency up to 86 %, the power supply can operate within a temperature range of -30 to 70 °C. Thanks to the constant current supply and overload protection, it has wide application possibilities in both home and industrial installations.

Key features

• Output voltage 24 V DC with regulation 21.6 to 29 V DC
• DIN rail mounting (width 17.5 mm)
• Wide input range 85 to 264 V AC
• Efficiency up to 86 %
• Plastic housing with protection against electric shock
• Constant current mode
• Overload protection
