MEAN WELL LRS-100-48 Industrial power supply, 110W, 48V

The stable switched-mode power supply offers a power output of 110 W with an output of 48 V/2.3 A for LED lighting, automation, security, and IT systems. Wide input range of 85–264 VAC / up to 373 VDC ensures trouble-free operation in various installations, while an efficiency of up to 91% reduces energy losses. Thanks to its compact dimensions, it easily fits into tight enclosures.

Comprehensive short-circuit, overload, and overvoltage protection protects connected electronics and enhances operational reliability. The rugged design allows operation in temperatures ranging from -30 to +70 °C, and the lifespan is supported by MTBF exceeding 720,000 hours. UL, TUV, and European certification guarantee safe operation and easy deployment in industrial and commercial applications.

Key Features

• Power 110 W
• Output 48 V / 2.3 A
• Adjustable output voltage 43.2-52.8 V
• Efficiency up to 91%
• Protection against short-circuits, overloads, and overvoltage
• Operating temperature -30 to +70 °C
• MTBF exceeding 720,000 hours
• Suitable for LED, automation, IT, and security systems
