MEAN WELL LRS-75-48 Industrial power supply, 77W, 48V

The switched power supply offers a reliable solution for industrial automation, LED technology, switchboards, and smart homes. Output voltage 48 V with a power of 77 W ensures stable power for a wide range of devices. Its compact design allows for easy installation even in space-constrained applications.

High efficiency of up to 91.5 % minimizes energy losses and limits heating. Integrated overload and overvoltage protections, along with UL, TUV, EN, and CCC certifications, enhance operational safety. Durable design with an operating temperature of up to 70 °C allows deployment in demanding conditions with long-term operation 24/7.

Key features

• Output voltage 48 V DC
• Output current 1.6 A
• Power 77 W
• Efficiency up to 91.5 %
• Voltage adjustment range 43.2 - 52.8 V
• Overload and overvoltage protection
• Operating temperature up to 70 °C
• MTBF up to 681 000 hours at 25 °C
• Suitable for industrial automation, LED applications, switchboards, and smart homes
