MEAN WELL MDR-40-48 Switching power supply for DIN rail 40W 48V

The MDR-40 series power supplies are affordable DIN rail-mounted supplies. The model MDR-40-48 provides a direct current output voltage of 48 V with an adjustable range of 48 V - 56 V. It can be mounted on TS-35/7.5 and TS-35/15 DIN rails, occupying 40 mm in width. The supply is ready for a wide input voltage range of from 85 V AC to 264 V AC and complies with the European standard EN 61000-3-2.

The outer casing of the supply is made of plastic, effectively protecting against electric shock. With efficiency of up to 88 %, the supply can operate in a temperature range of -20 to 70 °C. Thanks to its constant current output and overload protection, it has wide application possibilities in both domestic and industrial installations.

Key Features

• Output voltage 48 V DC
• Output adjustment range 48–56 V
• Input voltage 85–264 V AC
• Plastic housing for increased safety
• Efficiency up to 88 %
• Constant current mode
• Overload protection
• DIN rail mounting
