MEAN WELL MDR-60-24 switching power supply for DIN rail 60W 24V

The MDR-60 series power supplies are affordable ultra-thin power supplies. The MDR-60-24 model provides a direct current output voltage of 24 V with the ability to adjust within the range of 24 V - 30 V. It is mounted on DIN rails TS-35/7.5 and TS-35/15, taking up 40 mm in width. The power supply is prepared for a wide input voltage range of from 85 V AC to 264 V AC and complies with the European standard EN 61000-3-2.

The outer casing of the power supply is made of plastic, which effectively protects against electric shock. With an efficiency of up to 88 %, the power supply can operate in a temperature range of -20 to 70 °C. Thanks to the provision of constant current and overload protection, it has a wide range of applications in both household and industrial installations.

Key features

• Output voltage 24 V DC
• Output adjustment range 24–30 V
• Input voltage 85–264 V AC
• Plastic housing for increased safety
• Efficiency up to 88 %
• Constant current mode
• Overload protection
