MEAN WELL SDR-480P-48 Switching power supply for DIN rail, 480W, 48V

Switching power supply on DIN rail with a power of 480 W provides a stable output of 48 V / 10 A for automation, LED lighting, distribution boards, and security systems. Thanks to an efficiency of up to 94 %, it reduces energy losses and supports continuous operation. The option for parallel connection of up to 8 units allows for an increase in power up to 3840 W, while comprehensive protections against overload, overvoltage, and overheating ensure long-term reliability.

Key features

• Output voltage 48 V DC
• Output current 10 A
• Maximum power 480 W
• Efficiency up to 94 %
• Adjustable output voltage 48–55 V
• Parallel connection of up to 8 units (max. 3840 W)
• Protection against overload, overvoltage, and overheating
