Tinycontrol tBSm Splitter 3x RJ-12 for LAN controller LK4

The small universal splitter from Tinycontrol allows easy extension of a single-stranded cable with twisted pair and expansion of an RJ-12 port to three universal ports. It enables 1-Wire extension even at remote locations and is compatible with all TinyControl devices. The package includes a six-wire cable for connection to the LK4 LAN controller, which ensures stable bus connectivity.

Notice: Do not connect cables longer than 3 m for I2C or 1-Wire buses that are not from TinyControl and have more than 3 wires in the RJ-12 connector, as this may cause improper function of the I2C bus.

Key Features

• Spring connectors for quick connection
• 1-Wire extension even at remote locations
• Six-wire cable for connection to the LK4 LAN controller
• Support for twisted pair or wire gauge approximately 0.5 mm
• Splitting RJ-12 port into three universal ports
