Tinycontrol Waterproof Temperature Sensor DS18B20 for LAN Controller LK3 and LK4

The digital sensor offers exceptional temperature measurement accuracy in the range of -55 to +125 °C, ideal for industrial applications, home automation, and environmental monitoring. Thanks to compatibility with standard DS18B20 sensors and a pre-programmed unique serial ID, it allows for easy connection of multiple units on a single bus. The aluminum base ensures rapid heat transfer to the sensor, significantly improving measurement accuracy, while the programmable resolution of 9–12 bits provides flexible precision settings for various applications.

Easy installation and durable construction

The miniature Push Wire connector allows for quick and simple wire connections up to a cross-section of 0.5 mm2 without the need for screws. The sensor is protected by resin against moisture and mechanical damage with an IP44 rating, withstands electrostatic discharges of up to 8000 V, and has an extremely low power consumption of just 1 µA in standby mode. A wide power supply voltage range of 2.5–5.5 V DC ensures universal application in various systems and applications, making the sensor an ideal choice for accurate and reliable temperature measurement.

Key features

• Sensor type: digital temperature sensor
• Bus: 1-Wire
• Converter resolution: programmable 9–12 bits
• Precise temperature measurement -55 to +125 °C
• Measurement accuracy: ± 0.4 °C (in the range of -10 to +85 °C)
• Compatibility with standard DS18B20 sensors
• Push Wire connector for easy installation
• Wide power supply voltage range of 2.5 to 5.5 V DC
• Protection against electrostatic discharge (ESD) over 8000 V
• Extremely low power consumption
• Degree of protection: IP44
• Identification: unique serial ID for each sensor
