TP-Link CPE220

TP-LINK 2.4GHz 300Mbit/s 12dBi outdoor CPE device CPE220 is designed for inexpensive solutions for outdoor wireless network applications. Its centralized management system makes it ideal for point-to-point, point-to-multipoint and outdoor wireless network coverage. Professional performance together with a user-friendly design make the CPE220 an ideal choice for work and home use.

• Built-in 12dBi 2x2 directional dual-polarized MIMO antenna
• Adjustable transmission power from 0 to 30dBm/1000mW
• System-level optimization for more than 13km wireless transmission range
• TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves device performance in terms of throughput, capacity and latency, ideal for PTMP applications
• Centralized control system - Pharos control
• Operating modes AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP)
• The passive PoE adapter supports power over Ethernet up to 60 meters and enables remote device reset

Hardware for business solutions

With Qualcomm Atheros enterprise-grade chipsets, high-gain antennas and high-quality material used, specially designed housing and PoE power supply, the CPE220 is primarily designed for outdoor use and can function flawlessly in almost any climate, with an operating temperature ranging from -30°C to +70°C.

TP-LINK MAXtream TDMA technology

Due to the ever-increasing network scale, the mutual interference and collision of wireless networks between CPE devices and base stations will be so great that the actual network throughput will decrease, which will be very negatively felt by the end users. To mitigate these negative effects, the CPE220 uses MAXtream TDMA technology.

Pharos Management - Centralized Management System

The CPE220 is also equipped with centralized control software that helps users easily manage all devices in their network from a single computer - Pharos Control. Functions such as device discovery, health monitoring, firmware updates and network maintenance can be managed using Pharos control.

Package contents

• Device
• PoE power adapter
• Power cord
• (2) duct tape
