Triton 19" standing rack 45U/600x800 glass door, grey

A reliable solution for data and network technologies offers a sturdy welded structure with high load capacity and easy access to all installed components. Load capacity of up to 800 kg allows safe installation of even heavier equipment, while the dimensions of 45U, width of 600 mm, and depth of 800 mm provide ample space for professional assembly. The glass doors made of 4 mm tempered safety glass ensure visibility of the equipment while protecting the installed components.

Removable side panels and rear cover significantly facilitate installation, servicing, and cable organization. Adjustable 19" vertical rails allow the internal space to be adapted for various types of devices, while doors with an opening angle of up to 165° provide comfortable access. The cabinet offers preparation for the installation of a ventilation unit, cable entries with knock-out blanks, and IP20 protection. 4 mm thick tempered safety glass enhances safety and durability during everyday use.

Key features

• Height 45U (2105 mm)
• Dimensions 600 × 800 mm
• Load capacity of up to 800 kg
• Welded robust construction
• IP20 protection
• Glass doors made of 4 mm tempered safety glass
• Door opening up to 165°
• Removable side panels and rear cover
• Adjustable 19" vertical rails
• Preparation for the installation of a ventilation unit
• Knock-out cable entries with blanks

Box contents

• Floor-mounted cabinet
• (2) key - removable covers
• (2) key - front doors
• (16) floating nuts M6
• (16) screw M6 × 12
• (16) plastic washer 6.4
• (4) leveling screw/foot for cabinet
• (4) nut M10
• Dust cover
• Edge trim 1 m
